Module 5: The Interface (Next.js & Vercel AI SDK)

The Frontend

---

Introduction: From CLI to Production UI

Up until now, we've been building agents that run in the terminal. But real applications need:

• Beautiful, responsive interfaces
• Real-time streaming responses
• Rich, interactive components
• Seamless backend integration

This module teaches you how to build production-grade AI interfaces using Next.js and the Vercel AI SDK's UI hooks.

---

5.1 Streaming UI

Why Streaming Matters

Compare these user experiences:

Without Streaming:

User: "Explain quantum computing"
[30 seconds of loading spinner]
Agent: [Entire response appears at once]

With Streaming:

User: "Explain quantum computing"
Agent: "Quantum computing is..." [text appears word by word in real-time]

Streaming creates a sense of responsiveness and lets users start reading immediately.

The useChat Hook

The Vercel AI SDK provides useChat—a React hook that handles:

• Message history
• Streaming responses
• Loading states
• Error handling

Basic Next.js setup:

npx create-next-app@latest my-ai-app
cd my-ai-app
npm install ai @ai-sdk/openai

Create API route: app/api/chat/route.ts

import { streamText } from 'ai'
import { openai } from '@ai-sdk/openai'

export const runtime = 'edge'

export async function POST(req: Request) {
  const { messages } = await req.json()

  const result = streamText({
    model: openai('gpt-4-turbo'),
    messages
  })

  return result.toDataStreamResponse()
}

Create chat UI: app/page.tsx

'use client'

import { useChat } from 'ai/react'

export default function ChatPage() {
  const { messages, input, handleInputChange, handleSubmit, isLoading } = useChat()

  return (
    <div className="flex flex-col h-screen max-w-2xl mx-auto p-4">
      {/* Messages */}
      <div className="flex-1 overflow-y-auto space-y-4 mb-4">
        {messages.map(message => (
          <div
            key={message.id}
            className={`p-4 rounded-lg ${
              message.role === 'user'
                ? 'bg-blue-100 ml-auto max-w-[80%]'
                : 'bg-gray-100 mr-auto max-w-[80%]'
            }`}
          >
            <p className="font-semibold mb-1">
              {message.role === 'user' ? 'You' : 'Agent'}
            </p>
            <p>{message.content}</p>
          </div>
        ))}

        {isLoading && (
          <div className="bg-gray-100 p-4 rounded-lg mr-auto max-w-[80%]">
            <p className="font-semibold mb-1">Agent</p>
            <p className="text-gray-500">Thinking...</p>
          </div>
        )}
      </div>

      {/* Input */}
      <form onSubmit={handleSubmit} className="flex gap-2">
        <input
          value={input}
          onChange={handleInputChange}
          placeholder="Ask me anything..."
          className="flex-1 p-3 border rounded-lg"
        />
        <button
          type="submit"
          disabled={isLoading}
          className="px-6 py-3 bg-blue-600 text-white rounded-lg disabled:opacity-50"
        >
          Send
        </button>
      </form>
    </div>
  )
}

Run it:

npm run dev

You now have a full-stack, streaming AI chat app!

Showing Tool Usage

Display what tools the agent is using:

// API route: app/api/chat/route.ts
import { streamText, tool } from 'ai'
import { openai } from '@ai-sdk/openai'
import { z } from 'zod'

const tools = {
  getWeather: tool({
    description: 'Get current weather for a location',
    parameters: z.object({
      city: z.string()
    }),
    execute: async ({ city }) => {
      // Mock data
      return {
        city,
        temperature: 72,
        condition: 'Sunny'
      }
    }
  })
}

export async function POST(req: Request) {
  const { messages } = await req.json()

  const result = streamText({
    model: openai('gpt-4-turbo'),
    messages,
    tools,
    maxSteps: 5
  })

  return result.toDataStreamResponse()
}

// Frontend: app/page.tsx
'use client'

import { useChat } from 'ai/react'

export default function ChatPage() {
  const { messages, input, handleInputChange, handleSubmit, isLoading } = useChat()

  return (
    <div className="flex flex-col h-screen max-w-2xl mx-auto p-4">
      <div className="flex-1 overflow-y-auto space-y-4 mb-4">
        {messages.map(message => (
          <div key={message.id}>
            {/* User/Assistant messages */}
            <div className={`p-4 rounded-lg ${
              message.role === 'user' ? 'bg-blue-100' : 'bg-gray-100'
            }`}>
              <p className="font-semibold">{message.role === 'user' ? 'You' : 'Agent'}</p>
              <p>{message.content}</p>
            </div>

            {/* Tool calls */}
            {message.toolInvocations?.map((tool, index) => (
              <div key={index} className="mt-2 p-3 bg-yellow-50 rounded border border-yellow-200">
                <p className="text-sm font-mono">
                  🛠️ Using tool: <strong>{tool.toolName}</strong>
                </p>
                <pre className="text-xs mt-1 overflow-auto">
                  {JSON.stringify(tool.args, null, 2)}
                </pre>
                {tool.result && (
                  <pre className="text-xs mt-1 overflow-auto text-green-700">
                    Result: {JSON.stringify(tool.result, null, 2)}
                  </pre>
                )}
              </div>
            ))}
          </div>
        ))}
      </div>

      <form onSubmit={handleSubmit} className="flex gap-2">
        <input
          value={input}
          onChange={handleInputChange}
          placeholder="Ask me anything..."
          className="flex-1 p-3 border rounded-lg"
        />
        <button type="submit" disabled={isLoading} className="px-6 py-3 bg-blue-600 text-white rounded-lg">
          Send
        </button>
      </form>
    </div>
  )
}

---

5.2 Generative UI

Beyond Text: Rendering Components

What if instead of text, the agent could render:

• Interactive charts
• Formatted tables
• Buttons and forms
• Custom React components

This is Generative UI—the agent generates UI components, not just text.

Using streamUI

// API route: app/api/chat/route.ts
import { streamUI } from 'ai/rsc'
import { openai } from '@ai-sdk/openai'
import { z } from 'zod'
import { StockChart } from '@/components/StockChart'

const tools = {
  showStockChart: tool({
    description: 'Display a stock price chart',
    parameters: z.object({
      ticker: z.string(),
      period: z.enum(['1D', '1W', '1M', '1Y'])
    }),
    generate: async function* ({ ticker, period }) {
      yield <div className="text-gray-500">Loading chart for {ticker}...</div>

      const data = await fetchStockData(ticker, period)

      return <StockChart ticker={ticker} data={data} period={period} />
    }
  })
}

export async function POST(req: Request) {
  const { messages } = await req.json()

  const result = await streamUI({
    model: openai('gpt-4-turbo'),
    messages,
    tools,
    text: ({ content }) => <p>{content}</p>
  })

  return result.toDataStreamResponse()
}

Frontend:

'use client'

import { useChat } from 'ai/react'

export default function Page() {
  const { messages } = useChat({
    api: '/api/chat'
  })

  return (
    <div>
      {messages.map(message => (
        <div key={message.id}>
          {message.ui || message.content}
        </div>
      ))}
    </div>
  )
}

Result:

When the user asks "Show me Apple's stock chart", instead of text, they get an actual interactive React component rendered inline!

Example: Weather Card Component

// components/WeatherCard.tsx
export function WeatherCard({ city, temperature, condition }: {
  city: string
  temperature: number
  condition: string
}) {
  return (
    <div className="bg-gradient-to-br from-blue-400 to-blue-600 text-white p-6 rounded-xl shadow-lg max-w-sm">
      <h2 className="text-2xl font-bold">{city}</h2>
      <div className="flex items-center justify-between mt-4">
        <div className="text-5xl font-bold">{temperature}°F</div>
        <div className="text-xl">{condition}</div>
      </div>
    </div>
  )
}

// API route
const tools = {
  getWeather: tool({
    description: 'Get weather and display a card',
    parameters: z.object({
      city: z.string()
    }),
    generate: async function* ({ city }) {
      yield <div>Checking weather...</div>

      const data = await fetchWeather(city)

      return <WeatherCard city={city} temperature={data.temp} condition={data.condition} />
    }
  })
}

---

5.3 Deployment

Deploying to Vercel

Vercel is the fastest way to deploy Next.js apps.

1. Install Vercel CLI:

npm i -g vercel

2. Deploy:

vercel

That's it. Your AI agent is live in production.

3. Add Environment Variables:

Go to your Vercel dashboard → Settings → Environment Variables:

OPENAI_API_KEY=sk-...
SUPABASE_URL=https://...
SUPABASE_KEY=eyJ...

Handling Timeouts

Serverless functions have time limits (typically 10-60 seconds). For long-running tasks:

Option 1: Edge Runtime

export const runtime = 'edge' // No timeout, but limited Node.js APIs

Option 2: Background Jobs with Inngest

npm install inngest

// inngest/functions.ts
import { inngest } from './client'

export const researchAgent = inngest.createFunction(
  { id: 'research-agent' },
  { event: 'research/start' },
  async ({ event, step }) => {
    const results = await step.run('search-web', async () => {
      return await searchWeb(event.data.query)
    })

    const analysis = await step.run('analyze', async () => {
      return await analyzeResults(results)
    })

    await step.run('send-email', async () => {
      return await sendEmail(event.data.email, analysis)
    })
  }
)

Trigger from API:

// app/api/research/route.ts
import { inngest } from '@/inngest/client'

export async function POST(req: Request) {
  const { query, email } = await req.json()

  await inngest.send({
    name: 'research/start',
    data: { query, email }
  })

  return Response.json({ message: 'Research started' })
}

Option 3: Streaming for Long Tasks

Keep the connection alive with streaming:

export async function POST(req: Request) {
  const encoder = new TextEncoder()

  const stream = new ReadableStream({
    async start(controller) {
      controller.enqueue(encoder.encode('data: Starting research...\n\n'))

      const results = await searchWeb(query)
      controller.enqueue(encoder.encode(`data: Found ${results.length} results\n\n`))

      const analysis = await analyzeResults(results)
      controller.enqueue(encoder.encode('data: Analysis complete\n\n'))

      controller.enqueue(encoder.encode(`data: ${JSON.stringify(analysis)}\n\n`))
      controller.close()
    }
  })

  return new Response(stream, {
    headers: {
      'Content-Type': 'text/event-stream',
      'Cache-Control': 'no-cache',
      'Connection': 'keep-alive'
    }
  })
}

---

Complete Production Example

File structure:

my-ai-agent/
├── app/
│   ├── api/
│   │   └── chat/
│   │       └── route.ts
│   ├── page.tsx
│   └── layout.tsx
├── components/
│   ├── ChatInterface.tsx
│   └── StockChart.tsx
├── lib/
│   ├── tools.ts
│   └── supabase.ts
└── package.json

lib/tools.ts:

import { tool } from 'ai'
import { z } from 'zod'
import { searchWeb, scrapeWebsite } from './research'
import { searchDocuments } from './supabase'

export const tools = {
  searchKnowledgeBase: tool({
    description: 'Search internal company documents',
    parameters: z.object({
      query: z.string()
    }),
    execute: async ({ query }) => {
      const results = await searchDocuments(query)
      return results.map(r => r.content).join('\n\n')
    }
  }),

  researchWeb: tool({
    description: 'Research a topic by searching and reading web pages',
    parameters: z.object({
      query: z.string()
    }),
    execute: async ({ query }) => {
      const results = await searchWeb(query)
      const content = await scrapeWebsite(results[0].url)
      return { source: results[0].url, content: content.slice(0, 2000) }
    }
  })
}

app/api/chat/route.ts:

import { streamText } from 'ai'
import { openai } from '@ai-sdk/openai'
import { tools } from '@/lib/tools'

export const runtime = 'edge'

export async function POST(req: Request) {
  const { messages } = await req.json()

  const result = streamText({
    model: openai('gpt-4-turbo'),
    messages,
    tools,
    maxSteps: 5,
    system: 'You are a helpful research assistant. Use tools to find information.'
  })

  return result.toDataStreamResponse()
}

app/page.tsx:

'use client'

import { useChat } from 'ai/react'

export default function Page() {
  const { messages, input, handleInputChange, handleSubmit, isLoading } = useChat()

  return (
    <div className="min-h-screen bg-gray-50">
      <div className="max-w-3xl mx-auto p-6">
        <h1 className="text-3xl font-bold mb-6">Research Agent</h1>

        <div className="bg-white rounded-lg shadow-lg p-4 mb-4 h-[600px] overflow-y-auto">
          {messages.map(m => (
            <div key={m.id} className={`mb-4 ${m.role === 'user' ? 'text-right' : ''}`}>
              <div className={`inline-block p-4 rounded-lg ${
                m.role === 'user' ? 'bg-blue-500 text-white' : 'bg-gray-100'
              }`}>
                {m.content}
              </div>
            </div>
          ))}
        </div>

        <form onSubmit={handleSubmit} className="flex gap-2">
          <input
            value={input}
            onChange={handleInputChange}
            className="flex-1 p-4 border rounded-lg"
            placeholder="Ask me to research anything..."
          />
          <button
            type="submit"
            disabled={isLoading}
            className="px-8 py-4 bg-blue-600 text-white rounded-lg font-semibold disabled:opacity-50"
          >
            Send
          </button>
        </form>
      </div>
    </div>
  )
}

Deploy with vercel and you have a production AI research agent!

---

Key Takeaways

1. useChat hook handles streaming, state, and UI updates automatically
2. Streaming provides better UX than waiting for complete responses
3. Generative UI lets agents render React components instead of just text
4. Vercel makes deployment trivial
5. Edge runtime avoids timeouts for long-running agents

---

Exercise: Build a Multi-Modal Agent

Create an agent that can:

1. Display stock charts when asked about stocks
2. Show weather cards when asked about weather
3. Render a table when comparing data
4. Stream text responses for general questions

---

Next up: Module 6 – The Capstone Project, where you build a complete Business Analyst Agent.
